Applications include

Civil/domestice: water supply systems, pressure boosting sytems, air conditioning & heating

Agriculture: Sprinkler or flow irrigation

Industrial: Water Supply systems, Washing plants, Transfer of non aggressive fluids

• Standard: manufactured to D/N 24255
• Liquids: clean water or non-aggressive liquids compatible with AISI 304 stainless steel.
• Maximum liquid temperature: 90° C
• Maximum working pressure: 10 bar
• 304 stainless steel: pump casing, casing cover, impeller
• 303 stainless steel: pump shaft which comes in contact with the liquid.
• Sealing arrangement: mechanical seal to DIN 24960.
• Suction/discharge flanges: manufactured to DIN 2532.
• Range of pumps from 1.1KW to 15KW

A set of suction/discharge counter flanges made from standard forged steel (FE 42) can be supplied as an accessory.
